Phoenix, AZ, Feb. 22, 2008 – ON Semiconductor (Nasdaq: ONNN) today introduced a GreenPoint™ open reference design for a 16 watt (W) ac-dc adapter for xDSL modems. This design exceeds ENERGY STAR® requirements for single voltage ac-dc and ac-ac external power supplies revision 1.1, for high active-mode power efficiency and low standby-mode power consumption. The reference design can also be easily modified for use with 10-20 W, single output-voltage adapters for printers, routers, and hubs.
This fully-implemented and tested solution achieves active-mode efficiency of 78 percent at 120 Vac and 79 percent at 230 Vac, exceeding ENERGY STAR® guidelines of 74 percent for both input voltages. In standby-mode, the solution consumes only 240 milliwatts (mW) at 120 Vac and 200 mW at 240 Vac, exceeding ENERGY STAR® guidelines of 0.5 W for both input voltages. In addition, the design complies with FCC Part 15 Level B EMI requirements.
“ON Semiconductor’s new 16 W GreenPoint™ reference design expands the power range of ON Semiconductor’s portfolio of efficient reference designs for ac-dc adapters,” said Andy Williams, senior vice president and general manager of ON Semiconductor’s Automotive and Power Regulation Group. “By utilizing this proven solution, customers can quickly deploy consumer products that comply with evolving efficiency standards in a wide variety of geographic markets.”
The reference design addresses all functional blocks of the adapter, utilizing several of ON Semiconductor’s power management devices and drawing from its leading discrete component portfolio to achieve superior efficiency performance.
Key Products in the Reference Design Include:
• NCP1027: This high voltage switcher includes a power MOSFET together with a startup current source, all directly connected to the bulk capacitor. To prevent lethal runaway in low input voltage conditions, an adjustable brown-out circuit blocks the activity until a sufficient input level is reached. Offered in a PDIP-7 package, the NCP1027 is priced at $0.97 per unit in 1,000-unit quantities.
• MURS160: This 1 ampere (A), 600 volt (V) Ultrafast Rectifier is offered in an SMB package and priced at $0.20 per unit in 2,500-unit quantities.
• MBRS360: This 3 A, 60 V Schottky Rectifier is offered in an SMC package and priced at $0.33 per unit in 2,500-unit quantities.
• MMSD4148: This 100 V Switching Diode is offered in an SOD-123 package and priced at $0.04 per unit in 10,000-unit quantities.
• MMSZ5241B: This 500 mW Zener Diode, offered in an SOD-123 package and priced at $0.04 per unit in 3,000-unit quantities.
All of these devices are RoHS compliant and are delivered in Pb-free packages.
ON Semiconductor has a complete documentation package for the 16 W ac-dc adapter reference design, including description, schematics, bill-of-materials, Gerber files and evaluation guidelines. The documentation package is available at www.onsemi.com/greenpoint,
as are links to relevant industry information and other supporting information. For more information, contact Christophe Warin at Christophe.Warin@onsemi.com.
A live demonstration of a 16 W ac-dc xDSL modem adapter utilizing this GreenPoint™ reference design will be on display at the ON Semiconductor booth (No. 210) at the Applied Power Electronics Conference (APEC) to be held in Austin, TX, from Feb. 25-27. For more information about the show, visit https://www.apec-conf.org/.
GreenPoint reference designs enable more efficient systems by establishing the feasibility of meeting emerging energy efficiency standards with existing technology, and by setting performance benchmarks. ON Semiconductor’s GreenPoint reference designs are available for ATX, CRT TV, and LCD TV power supplies; and 5 W, 16 W, 40 W, 60 W, 90 W, and 200 W power adapters. To acquire documentation packages, visit https://www.onsemi.com and search on “GreenPoint”.
