NCV74204V1GEVB:  3.3 V / 50 mA LDO Evaluation Board

The NCV74204V1GEVB is a Reference Design for LIN transceiver with integrated low drop voltage regulator. The reference design can be interfaced via IO pins to an external microcontroller or simple switch board. The boards are intended to give designers easy, quick and convenient means for evaluation of NCV7420 devices. The design incorporates the lowest bill of material and small board size.
Evaluation/Development Tool Information
Product Status Compliance Short Description Parts Used Action
NCV74204V1GEVB Active
Pb-free
3.3 V / 50 mA LDO Evaluation Board NCV7420D24R2G
Technical Documents
Type Document Title Document ID/Size Rev
Eval Board: Manual NCV7420 LIN Transceiver with Voltage Regulator Evaluation Board User's Manual EVBUM2044/D - 466.0 KB  0
Eval Board: BOM NCV74204V1GEVB Bill of Materials ROHS Compliant NCV74204V1GEVB_BOM_ROHS.PDF - 100.0 KB  0
Eval Board: Gerber NCV74204V1GEVB Gerber Layout Files (Zip Format) NCV74204V1GEVB_GERBER.ZIP - 117.0 KB  0
Eval Board: Schematic NCV74204V1GEVB Schematic NCV74204V1GEVB_SCHEMATIC.PDF - 192.0 KB  0
Eval Board: Test Procedure NCV74204V1GEVB Test Procedure NCV74204V1GEVB_TEST_PROCEDURE.PDF - 405.0 KB  0
