Evaluation Board | AP1302CSSL00SMGAH3-GEVB

The AR0145CSSM00SMKAH3-GEVB Sensor Board uses the high Global Shutter Efficiency AR0145 1MP Mono 0deg Global Shutter image sensor from onsemi. The sensor board can be interfaced to the Demo3 Evaluation Board, or with the AP1302 Evaluation Board stacked on Demo3 Evaluation Board. The combined kit uses the popular DevSuite software from onsemi to configure the system. The software provides a comprehensive setup interface and flexibility to evaluate the sensor’s features and capabilities.
The sensor board comes with a lens suitable for evaluation. Users can use their own lens as long as it is compatible with the mechanical & optical requirements.
To get started with the AR0145CSSM00SMKAH3-GEVB, you will also need:
Demo 3 Evaluation Board (AGB1N0CS-GEVK)
AP1302 Evaluation Board (optional)
DevSuite Software
